1. Project Overview & Site Execution
Located in Greece, this 100-200TPH production line is designed to maximize the value of local limestone resources by producing both construction aggregates and manufactured sand simultaneously. Featuring the PFW1315 European Impact Crusher, the plant efficiently shapes the stone while generating a high ratio of fines. The system outputs four specifications: 0-5mm sand, and 5-20mm, 20-50mm, 50-80mm aggregates, fulfilling the client's requirement for a versatile, high-return investment.
LOCATION
Greece
CAPACITY
100-200 TPH
MATERIAL
Limestone (Soft/Medium Hard)
PRODUCTS
0-5mm (Sand), 5-20mm, 20-50mm, 50-80mm
Project Site Snapshot & Execution Summary
This photo captures the primary crushing stage installation, utilizing a modular steel structure design which dramatically reduced on-site installation time and complexity.
"The PFW impact crusher is fantastic. It produces enough fines (0-5mm) for our sand needs while keeping the large aggregates (up to 80mm) in perfect cubical shape."
2. Detailed Process Flow & Design Rationale
To produce high-grade manufactured sand and aggregates simultaneously, we designed a complete three-stage "Crushing + Shaping" circuit:
- Primary Crushing: The PE-750×1060 Jaw Crusher reduces large limestone boulders to roughly 150mm.
- Secondary Crushing: The PFW1315 European Impact Crusher handles the medium crushing. Its heavy-duty rotor is perfect for processing soft-to-medium hard limestone.
- Sand Making (Tertiary): To ensure the highest quality of 0-5mm sand, the material enters the VSI5X Sand Maker. The "rock-on-rock" action shapes the particles into perfect cubes.
- Screening: An S5X-2160 Vibrating Screen separates the final products into 0-5mm (Sand), 5-20mm, and larger aggregates.
3. Key Equipment Configuration List
We selected market-leading, durable models to ensure stable 24/7 operation and low maintenance costs.
4. Project Highlights & Value Creation
Dual Functionality
The PFW Impact Crusher acts as both a secondary crusher and a sand maker, reducing the need for a separate VSI machine.
Premium Shape
Delivers excellent cubical aggregates (0-80mm) that meet strict European infrastructure standards.
EU Environmental Standard
The plant features a fully enclosed design and dust collection system to comply with Greek environmental regulations.
